| Model | Wattage | Color | Dimensions | Hole |
| LL-C 5035 DALI | 10-30W | White, CCT, RGB, RGBW or RGB + CCT | W50xH35xL(X)mm | W35x(X-15)mm |
| LL-C 5535 DALI | 20-40W | White, CCT, RGB, RGBW or RGB + CCT | W55xH35xL(X)mm | W40x(X-15)mm |
| LL-C 6535 DALI | 20-60W | White, CCT, RGB, RGBW or RGB + CCT | W65xH35xL(X)mm | W50x(X-15)mm |
| LL-C 7035 DALI | 20-60W | White, CCT, RGB, RGBW or RGB + CCT | W70xH35xL(X)mm | W55x(X-15)mm |
| LL-C 7535 DALI | 20-60W | White, CCT, RGB, RGBW or RGB + CCT | W75xH35xL(X)mm | W60x(X-15)mm |
| LL-C 9035 DALI | 20-80W | White, CCT, RGB, RGBW or RGB + CCT | W90xH35xL(X)mm | W75x(X-15)mm |
| X is the length(Outdoor Frame) you need. Any length can be customised/ Any Watts can be Customised |
||||
| Input | 220-240VAC/110-277VAC | LED Source | LM80 LEDs |
| Wattage | 10-80W | PF | >0.9 |
| Color Temperature | White, CCT, RGB, RGBW or RGB + CCT | Lumen Effective | >100LM/W |
| Angel | Aluminum+PC | CRI | >82 or 92 |
| Electrical Classification | Class II | IP Rating | IP42 |
| Beam Materials | 120° | Body Color | White/Black |
| Warranty | 3-5 years | DALI |
SAA CE ROHS |
